The Best Pelpro Vacuum Pressure Differential Switch

Universal Adjustable Vacuum Switch Kit. For use with GM 3L30, 4L30E, TH180, TH180C. OE Reference # K058 . Superior Vacuum Switch Kit.

GENERIC REPLACEMENT, NON-RETURNABLE

2L inc., #11120 Adjustable Vacuum Pressure Switch, Vacuum 5 – 30 in Hg.

Made in the USA.

Adjustable Vacuum Pressure Switch has both Normally Open and Normally Closed Quick Connect Terminals.

Simple to adjust Vacuum Switch with one thumbscrew.

Tight repeatable deadband for consistent operation.

10-32 vacuum port.

Two Mounting Holes for #6 SHCS.
– Includes One Push to Connect 1/8″ Tubing to 10-32 Connector.
– Includes Three Fully Insulated 14/16 Gauge Wire – 2.8mm (0.110″) Quick Disconnect Connectors.

Vacuum Range: 5 – 30 in Hg.
– Hysteresis / Deadband: 0.5 in Hg. – 2.5 in Hg (Average = 1.0 in Hg).

Electrical Rating : 5A 125-250VAC , 1A 48VDC.
– Terminals: Quick Connect 2.8 x 0.5mm (0.110′).
– Electrical Switch Approved according to EN 61058 and UL 1054.
– Ambient temperature -40 to max. +100 °C.

MULTICOMP PSF109S-81-330 PRESSURE SWITCH, VACUUM -2.9 TO -11.9PSI

QUADRA-FIRE, HEATILATOR, PELPRO & PLEASANT HEARTH VACUUM SWITCH Fits Quadra-Fire Models: ~ 800 ~ 1000 ~ 1100I ~ Castile FS ~ Castile Insert ~ Santa Fe FS ~ Santa Fe B ~ Santa Fe Insert ~ Classic Bay 1200 FS – CB1200 ~ Classic Bay Insert – CB1200I ~ Contour ~ Original Mt Vernon – 4 Spd Control ~ Mt Vernon AE FS ~ Mt Vernon AE Insert ~ Mt. Vernon E2 FS ~ Mt. Vernon E2 Insert ~ Edge 60 Insert Fits Heatilator & Pleasant Hearth Models: ~ Eco-Choice PS35 – PH35 ~ Eco- Choice PS50 – PH50 ~ Eco-Choice CAB50 Fits PelPro Models: ~ PP60 ~ PP130 ~ PPC90 ~ TSC90 Part Numbers: ~ SRV7000-166 | 812-3430 | 812-1990 | SRV7000-447 | SRV7000-531 | AMP-20097K Specs: ~ Differential Vacuum Pressure Switch, Includes Both Hoses ~ Senses air flow/restriction within the firebox, exhaust chamber, vent pipe and fuel hopper on select models. ~ The vacuum switch runs in circuit with the feed system. If the vacuum switch is faulty or senses a safety issue it will not allow the auger feed motor to operate. ~ Top Quality Aftermarket Part. Exceeds All OEM Standards. ~ 180 day manufacturer warranty with our no hassle replacement guarantee

Description
For measuring the ventilation and air condition systems. Widely used for gas measurement, calibration, and any troubleshooting of any gas pressure systems.
Made of ABS black body, white marking
Two pressure connector on the top
11 pressure units, kPa, psi, kgfcm2, ozin2, bar, mbar, inHg, mmHg, inH2O, ftH2O, cmH2O cycle selectable
Measuring of vacuum, and pressure of air pressure of the single pipe or differential pressure of 2 lines
Record for maximum, minimum and Average pressure
Over range too hi or too low symbol, Zero setting function
Power on/off, auto off in 10 minutes, Press HOLD button and Power on/off button together, the meter won’t auto power off until the battery use up.
Zero setting function
Battery replacement available

Include
A set of digital manometer includes
1 x Digital Manometer
2 x Plastic Hose
1 x Male Connector
1 x Carry Pouch
1 x 9V battery
1 x English Manual

Meaureman has 20 years rich experience in the measuring of pressure, temperature, flow, level industries, The “Measureman” branded products are the combination of continuous good quality and affordable price. “Measureman” products are selected and designed by professional engineers.

Description:
The MPXV7002 series piezoresistive transducer in the small outline package (SOP) is a state-of-the-art monolithic silicon pressure sensor.
It’s designed for a wide range of applications, and particularly those employing a microcontroller or microprocessor with A/D inputs.
This patented, single element transducer combines advanced micromachining techniques,
Thin-film metallization and bipolar processing which provide an accurate,
High level analog output signal that is proportional to the applied pressure.
In addition, with an offset specifically at 2.5V instead of the conventional 0V.
This new series allows to measure pressure up to 7kPa through each port for pressure sensing,
but also for vacuum sensing (refer to the transfer function in the data sheet for more detailed information).

Specification:
-2 to 2 kPa (-0.3 to 0.3 psi)
0.5 to 4.5 V Output
Weight: 0.1oz; 4g
Please see it to know more:http://code.google.com/p/ardupilot-mega/wiki/Airspeed

Package Content:
1x Differential Pressure Sensor Board
1x Free cables

2.5 HG 3-4.5GPH
