We spent many hours on research to finding 5 hp air compressor pressure switch, reading product features, product specifications for this guide. For those of you who wish to the best 5 hp air compressor pressure switch, you should not miss this article. 5 hp air compressor pressure switch coming in a variety of types but also different price range. The following is the top 10 5 hp air compressor pressure switch by our suggestions
708 reviews analysed
1. Heavy Duty Pressure Switch for Air Compressor 135-175 psi Four 4 Port 26 Amp by lefoo
2. Sunny Heavy Duty Air Pressure Control Switch, L1, 1 Port, 95-125 PSI, 25 Amp
3. Square D Pumptrol Pressure switch for compressed air compressor 9013FHG12J52M1X 95-125 psi With Unloader & On/Off Lever
Description
TECHNICAL INFO SHOWN BELOW. Range of product Square D Pumptrol Pressure sensor name 9013FH Pressure sensor size 150 psi Value of setting Off at 125 psi Electrical circuit type Power circuit Product specific application Control small electrically driven air compressors Quantity per set 1 Type of packing Individual Complementary Pressure sensor type Electromechanical pressure switch Controlled fluid Air (-22…257 °F) Adjustable range on rising pressure 70…150 psi Approximate adjustable differential 30 psi Destruction pressure 220 psi Pressure actuator Diaphragm Pressure switch type of operation Regulation between 2 thresholds Scale type Fixed differential Setting Internal Local display Without Contacts type and composition 2 NC, snap action, DPST-DB, Form YY Cable entry number 2 0.88 in cable entries with 0.84 in across flats UL 508 Electrical connection Screw-clamp terminals, clamping capacity: 5.261 mm² Screw-clamp terminals, clamping capacity: 10 AWG Fluid connection type 0.25 inch NPSF internal conforming to UL 508 Short circuit protection 20 A by cartridge fuse, type gG Materials in contact with fluid Nitrile (Buna-N) or equivalent rubber diaphragm Zinc plated steel or equivalent flange Material Noryl thermoplastic resin or equivalent cover Polypropylene cover Operating position Any position Motor power kW 0.75 kW (1 hp) at 575 V AC, 3 phases 0.75 kW (1 hp) at 460 V AC, 3 phases 2.2 kW (3 hp) at 230 V AC, 3 phases 1.5 kW (2 hp) at 115 V AC, 3 phases 1.1 kW (1.5 hp) at 115 V AC, 1 phase 1.5 kW (2 hp) at 230 V AC, 1 phase Electrical durability 100000 cycles at 10 cyc/mn Mechanical durability 300000 cycles Terminal block type 4 terminals Operating rate 10 cyc/mn [Ui] rated insulation voltage 575 V conforming to UL 508 Product weight 1 lb(US) Repeat accuracy +/- 3 % Terminals description ISO n°1 L1-T1 L2-T2
4. New H/D Pressure switch for air compressor 95-125 w/Unloader
Description
pressure switch is factory set to 95-125. Switch comes with unloader and on/off lever. 1/4″ female NPT connection
5. lefoo LF10-1H-1-NPT1/4-95-125 Pressure Switch
6. Powermate Vx 034-0199RP Pressure Switch
7. Pressure Switch for Air Compressor 95-125 psi Single Port HEAVY DUTY 26A Replaces HUBBELL FURNAS SQUARE D SIEMENS SEARS DEWALT CRAFTSMAN BLACK MAX JENNY BLACK AND DECKER
Description
Pressure switch for air compressor 95-125psi heavy duty 26A
8. Pressure switch for air compressor made by Furnas / Hubbell 69JF9LY 140-175 single port w/ unloader & on/off lever
9. Square D by Schneider Electric 9013FHG59J59M1X Air-Compressor Pressure Switch, 175 Psi Set Off, 40 Psi Fixed Differential, 1/4" Npt External, 2-Way Release Valve, Auto/Off Cut-Out Lever
10. Square D by Schneider Electric 9013FHG39J68M1X Air-Compressor Pressure Switch, 140 psi Set Off, 30 psi Fixed Differential, 1/4" NPT External, 2-Way Release Valve, Auto/Off Cut-Out Lever
Conclusion
By our suggestions above, we hope that you can found 5 Hp Air Compressor Pressure Switch for you.Please don’t forget to share your experience by comment in this post. Thank you!
